EN-12 Valor 3000 Series Scales
7. TECHNICAL DATA
The technical data is valid under the following ambient conditions:
Ambient temperature: 0°C to 40°C
Relative humidity: 10% to 95% relative humidity, non-condensing
Height above sea level: Up to 4000 m
Operability is assured at ambient temperatures between 0°C and 40°C
Power: AC adapter 9VDC @ 1.2A max. output
Protection: Protected against dust and water
Pollution degree: 2
Installation category: Class III
EMC: See Declaration of Conformity
7.1 Specifications
TABLE 7-1. SPECIFICATIONS
Model V31XH202 V31XH402 V31XH2 V31XH4 V31X501
Capacity 200 400 2000 4000 500
Repeatability (g) 0.01 0.1
Linearity (g) ±0.01 ±0.1
Approval Class -
Ingress Protection -
Weighing Units g, kg, lb, oz, lb:oz
Application Modes Weigh, Percent weighing, Specific Gravity, Fluid Ounces
Tare range To capacity by subtraction
Stabilization Time ≤3 seconds
Power
Requirements 9 VDC @ 1.2A max. AC adaptor (supplied)
or 4 C (LR14) batteries (not supplied)
Calibration Digital with external weight
Display Type 6-digit 7-segment LCD with white LED backlight
Display Size 15 mm / 0.6” digits
Keypad 3-button overlay
Pan Size
(mm / in)
120 / 4.7 146 x 158 / 5.7 x 6.2 120 / 4.7
Net Weight
(kg / lb)
1.2 / 2.6 1.3 / 2.9 1.2 / 2.6
Shipping Weight
(kg/lb)
2.0 / 4.3 2.1 / 4.6 2.0 / 4.3
