GE Healthcare CardioMem CM 4000 - Manual (Page 2)

GE imagination at work
GE Healthcare
P.O. Box 900, FIN-00031 GE, Finland
GE Direct United Kingdom: +44 (0)800 0329201
www.gehealthcare.com
DOC1246101/1112
©2012 General Electric Company – All rights reserved. General Electric Company reserves the right
to make changes in specifications and features shown herein, or discontinue the product described
at any time without notice or obligation.
* GE and GE Monogramm are trademarks of General Electric Company.
** All third party trademarks belong to their respective owners.
*** 120 hours achieved using the Panasonic EVOiA battery
GE Healthcare, a division of General Electric Company.
Not commercially available in all markets.
Not for sale in the U.S. Not cleared by the U.S. FDA.
Storage
Storage Type
Integrated micro-SD card
(non-removable)
Sampling Rate 1024 Hz
Resolution 12 Bit
Data storage 256 Hz, optional 1024 Hz
Memory capacity ≥ 1 GByte
Data transfer mode Hi-speed USB 2.0
Data transfer time
30 s (for 24 h, 3 channel
ECG)
Wireless Transmission
Wireless transmission
(Online-ECG and settings)
Optional Bluetooth 2.0 +
EDR, Class 2
Range (free field) Min. 5 m
HF frequency range 2.4 ... 2.5 GHz ISM-Band
HR output 0.5 ... 4.5 dBm
Classification
Product classification
IIa in accordance with
93/42/EEC
Classification of applied part Type CF (Cardiac Floating)
Defibrillation protection
Integrated in patient cable
(optional)
Ingress protection IP 64
UMDNS code 12-388
Environmental conditions
Operating conditions
Temperature +5 °C ... +45 °C;
Relative humidity 10 ... 95 %,
noncondensing
Storage and transport
conditions
Temperature –20 °C ... +65 °C;
Relative humidity 5 ... 95 %,
noncondensing
Scope of delivery
Recorder, pouch with waist belt, start-up kit with ECG
electrodes and batteries, user manual, quick start guide,
transport box Parameters
Specifications
Dimensions (W x H x D)
65 x 108 x 14.5 mm (CM 4000)
65 x 108 x 16.5 mm (CM 4000 B)
Weight (CM 4000)
76 g (without battery)
89 g (with battery)
Weight (CM 4000 B)
78 g (without battery)
99 g (with battery)
Battery Type (CM 4000)
1 x 1.5 V Alkaline (AAA)
1 x 1.2 V NiMH (AAA)
Battery Type (CM 4000 B)
1 x 1.5 V Alkaline (AA)
1 x 1.2 V NiMH (AA)
Operating time
48 h (CM 4000)
Up to 120 h *** (CM 4000 B)
(alkaline battery)
Controls
Event key and touch screen,
multi-lingual
Display
2.4”color display, 320 x 240
pixel
Connectors
Patient cable
Data transfer (Mini-USB)
Available patient cables
2 channels (5 leads)
3 channels (7 leads)
Parameters
ECG channels
2 or 3 independent, bipolar
channels
Bandwidth 0,05 ... 100 Hz
Input dynamic range ± 6 mV
Offset voltage range ± 300 mV
Pacemaker detection
Optional unipolar, bipolar and
biventricular systems
Pulse width 0,1 ... 2 ms
Pulse amplitude 2 ... 250 mV
Open lead detection Yes
Additional channels
Optional thoracic impedance
variations and activity
CardioMem CM 4000 + CM 4000 B
Technical Specifications
Manufactured by
