Issue 1.5.A

GX server – Version 1.5 – Users Manual

EVS Broadcast Equipment – September 2011

20

Setting

Description

VDCP Version

Version of the VDCP protocol to be used in communications

between the server and the controller. The versions

available are the following: ‘2000’, ‘1998’.
This field will not be displayed when a protocol other than

the VDCP protocol is selected in the Protocol field.

Genlock Phase

Phase of the genlock input on the GX server video board.

Enable OSD

Tick the check box to activate the OSD (status screen) on

the SDI output of the GX server.

Advanced Options

The advanced options are hidden by default. They allow

users to specify which information should be included in the

logs. They should only be modified by, or in agreement with

the EVS customer support.
