Issue 4.1.A Xedio Suite Version 4.1 – User’s Manual - Xedio Browse
EVS Broadcast Equipment – December 2011
14
3. Tabs Pane
The Tabs pane consists of two tabs: the Media tab and the Virtual Media
Properties tab.
3.1 THE MEDIA TAB
The Media tab is used to select the media to manage.
3.1.1 O
VERVIEW OF THE
M
EDIA
T
AB
The upper part of the Media tab gives access to the different filters which can be
applied to the media list.
At least two tabs exist on the left of the Media tab.
• The Filter 0 tab: The element list displays the list of all media present in the
database, or it returns the result of a search applied to the list.
• The Today tab: the element list shown the media with ‘creation date = today’.
Additional tabs are displayed when the users have saved filters applied to the
database. Refer to section ‘Using Saved Filters’ on page 24 for more details.
