EditRec – User Manual

EVS Broadcast Equipment

Issue 11.00.B

21

4.1.4 A

UDIO

C

HANNEL

A

SSIGN

C

ONFIGURATION

There are 4 keys as audio edit preset on the keyboard of BVE-9100. Physically 2

keys (A1&A2) but Shift enables to reach (A3&A4).
These 4 keys are directly linked to EDL. Display of edit preset information on the

monitor is as below.
“VA1234”. BVE-9100 can assign up to 4ch of digital audio per 1 key. This

assignment is made in menu:
Press “Shift” + “Setup” -> F3 “IDC” -> Select the EditRec port -> F4 Audio Channel

Assign

Normal Assign

KEY

D1

D2

D3

D4

D5

D6

D7

D8

1

X

2

X

3

X

4

X


Assign 2 channels to 1 key by Setup

KEY

D1

D2

D3

D4

D5

D6

D7

D8

1

X

X

2

X

X

3

X

X

4

X

X


Assign particular channel to 1 key by Setup

KEY

D1

D2

D3

D4

D5

D6

D7

D8

1

X

X

X

X

2

X

X

3

X

X

4


Following this assignment, the information DA1 to DA8 and A1 to A2 are sent

through the 9-pin RS422 CMD and interpreted by the VTR.
