4. The Channel Pane
4.1. Introduction
The Channel pane shows the status of all playout servers individually. Each playout
server corresponds to one output channel.
4.2. Overview of the Channel Pane
The upper part of the Channel pane provides transport buttons and timecode fields. The
Play buttons become available as soon as a Playlist pane is connected to a playout
server.
The lower part of the Channel pane displays the elements of the playlist as soon as the
playlist is loaded on the output channel.
When the playlist is being broadcasted, the pane displays the list of remaining items to
play. Different colors are used to highlight the clip currently playing and the preloaded
clips.
4.3. Transport Controls and Timecode
Fields
The transport controls available from the Channel pane are the same as those provided in
the Playlist pane. See section "Transport Controls" on page 10 for more information.
The Timecode fields can show either the playing clip remaining timecode or the clip
elapsed timecode. These options are available when you right-click on the Timecode
fields.
