QUICK REFERENCE GUIDE

HOOKING UP & EXTENDING FOR TOWING

Align vehicles in approximate towing position with
straight driveway ahead and parking brakes locked.

Remove spring lock pin from fold up tabs and rotate
legs up to unfold tow bar. Partially extend legs and pin
baseplate connectors between attachment tabs.

Disengage parking brakes, unlock towed vehicle
steering wheel, and drive towing vehicle forward until
both legs are locked. (Red rubber seals are not visible)

Install safety cables and towed vehicle lighting.

UNHOOKING & FOLDING FOR STORAGE

Park vehicles in a straight line on level surface. Apply
towing vehicle parking brake. Place towed vehicle in
park or 1st gear for manual transmissions.

Remove safety cables and towed vehicle lighting.

Disengage leg latches (Red rubber seals are visible)
and remove connector pins.

Compress and place legs together. Fold legs towards
towing vehicle and lock in place with spring lock pin
through fold up tabs. Rotate legs down to engage
retainer pin in pivot bracket slot.
