4.4 How to set TR151-SP enter Geo-fence mode?
Users can set up to 10 permissible or restricted areas whose shape is circular or rectangular for
TR151-SP to track the vehicles or monitor the equipment/assets. The command media could be
SMS or GPRS. Users can choose to receive alarm message while TR151-SP enters the
restricted areas or to receive alarm message while TR151-SP gets out the permissible areas.
The content of the command includes the rectangular or circular areas defined by longitudes and
latitudes, getting in the restricted areas or getting out the permissible areas to send alarm, time
intervals of alarm report, number of reports, report format and return phone number.
The format of command is as below.
SMS Command media for Geo-fence mode
SMS Geo-fence
?4,IMEI,{[R,longitude,latitude,longitude,latitude],[C,longitude,latitude,radius(meter)]},In_or_
Out,Report_Interval,Number_of_Reports,Report_Format,Report_Phone_Number!
GPRS Geo-fence
?11,IMEI,{[R,longitude,latitude,longitude,latitude],[C,longitude,latitude,radius(meter)]},In_or_
Out,Report_Interval,Number_of_Reports,Report_Format,Return_Phone_Number!
SMS and GPRS
Geo-fence ?23,IMEI,{[R,longitude,latitude,longitude,latitude],[C,longitude,latitude,radius(meter)]},In_or
_Out,Report_Interval,Number_of_Reports,Report_Format,Report_Phone_Number!
GPRS Command media for Geo-fence mode
SMS Geo-fence
$4,IMEI,{[R,longitude,latitude,longitude,latitude],[C,longitude,latitude,radius(meter)]},In_or_
Out,Report_Interval,Number_of_Reports,Report_Format,Report_Phone_Number!
GPRS Geo-fence
$11,IMEI,{[R,longitude,latitude,longitude,latitude],[C,longitude,latitude,radius(meter)]},In_or_
Out,Report_Interval,Number_of_Reports!
SMS and GPRS
Geo-fence $23,IMEI,{[R,longitude,latitude,longitude,latitude],[C,longitude,latitude,radius(meter)]},In_or
_Out,Report_Interval,Number_of_Reports,Report_Format,Report_Phone_Number!
The description of SMS
Format Description
?4,$4
?11,$11
?23,$23
Start sign and function code
?4,$4
Æ Send location info to mobile phone.
?11,$11 Æ Send location info to GPRS server
?23,$23 Æ Send location info to mobile phone and GPRS server
IMEI IMEI of TR151-SP
{[R,longitude,latitude,longitude,latitude],[C,lo
ngitude,latitude,
radius(meter)]}
Boundary information:
R: rectangular shape
Æ Follow by two longitudes, latitudes.
C: circular shape Æ Follow by one longitude, latitude and one
radius.
In_or_Out
In_or_Out=in Æ Send alarm message if TR151-SP gets in the
restricted areas.
In_or_Out=out
Æ Send alarm message if TR151-SP gets
