7. Lift the power supply out of the computer.
Replacing the Power Supply
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
1. Slide the power supply into place.
2. Reattach the screws that secure the power supply to the back of the computer frame.
3. Reconnect the DC power cables.
NOTICE: You must route the DC power cables properly through the routing clips when you replace the cables to
prevent them from being pinched or crimped.
4. Route the cables through the routing clips, and press the clips to close them over the cables.
5. Replace the computer cover .
NOTICE: To connect a network cable, first plug the cable into the network port or device and then plug the cable into
the computer.
6. Connect your computer and devices to electrical outlets, and turn them on.
