Konfiguracja szafy serwerowej typu rack – Dell PowerEdge C8000 User Manual
Page 234
232
Rozpoczęcie pracy z systemem
Konfiguracja szafy serwerowej typu rack
Poniższa ilustracja przedstawia przykładową konfigurację z obudowami
serwerowymi PowerEdge C8000, jednostkami dystrybucji zasilania (PDU),
przełącznikiem i routerem w szafie typu rack o pojemności 42U.
UWAGA:
Ilustracja konfiguracji szafy typu rack ma wyłącznie charakter informacyjny.
4U
4U
3U
4U
4U
4U
4U
3U
4U
4U
1U
1U
1U
1U
