English | 15

Bosch Power Tools

2 609 140 479 | (22.1.08)

Functional Description

Read all safety warnings and all in-
structions.
Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.

Intended Use

The machine is intended for dry sanding of
wood, plastic, filler and coated surfaces.

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.

1 On/Off switch
2 Lock-on button for On/Off switch
3 Dust box, complete (micro filtersystem)
4 Rear clamping bracket
5 Release lever for rear clamping bracket
6 Sanding plate
7 Sanding sheet
8 Release button for front clamping bracket
9 Front clamping bracket

10 Extraction outlet
11 Filter element (micro filtersystem)
12 Vacuum hose*
13 Perforating tool
14 Screws for sanding plate

*The accessories illustrated or described are not in-
cluded as standard delivery.

Technical Data

Noise/Vibration Information

Measured values determined according to
EN 60745.
Typically the A-weighted noise levels of the
product are: Sound pressure level 80 dB(A);
Sound power level 91 dB(A). Uncertainty
K =3 dB.
Wear hearing protection!
Vibration total values (triax vector sum) deter-
mined according to EN 60745:
Vibration emission value a

h

=5.5 m/s

2

, Uncer-

tainty K =1.5 m/s

2

.

The vibration emission level given in this infor-
mation sheet has been measured in accordance
with a standardised test given in EN 60745 and
may be used to compare one tool with another.
It may be used for a preliminary assessment of
exposure.

Orbital sander

GSS 23 A

Professional

Article number

3 601 K70 4..

Rated power input

W

190

No-load speed

rpm

12000

No-load orbital stroke
rate

opm

24000

Orbit diameter

mm

2.0

Sanding sheet dimen-
sions
— Attachment via clamp-
ing

mm

93 x 230

Sanding plate dimen-
sions

mm

92 x 182

Weight according to
EPTA-Procedure
01/2003

kg

1.7

Protection class

/II

The values given are valid for nominal voltages [U] of
230/240 V. For lower voltage and models for specific
countries, these values can vary.
Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.
