Italiano – ASRock H61DE__S3 User Manual
Page 70
70
ASRock H61DE/S3 Motherboard
Italiano
Header HDMI_SPDIF
Header HDMI_SPDIF, con
(2-pin HDMI_SPDIF1)
uscita audio SPDIF su scheda
(vedi p.2 Nr. 29)
HDMI VGA, consente al
sistema di collegare dispositivi
per TV digitale HDMI/proiettori/
LCD . Collegare il connettore
HDMI_SPDIF della scheda
VGA HDMI a questo header.
