DRO 100 Readout Specifications
13
Readout Specifications
Characteristic Specification
Operating conditions 0° to 40°C (32° to 104°F)
25% to 85% relative humidity (non-condensing)
Storage conditions -40° to 60 ° C (-40° to 140 ° F)
25% to 95% relative humidity (non-condensing)
Input requirements
Voltage:
Frequency:
Current:
115VAC or 230VAC (+/-20%), single phase
47-63 Hz
150ma @115V, 75ma @230V
Fuse 115V operation: ½ A, 250V, 3AG, Slo-blo
230V operation: ¼ A, 250V, 3AG, Slo-blo
Encoder input Position signals: channels A & B
TTL square wave signal in quadrature
(90
° nominal phase relationship)
Maximum input rate: 50 kHz
Reference signal: TTL square wave
Size 9.875”W x 4.625”D x 4.75H”
Weight 7 lbs.
Mounting Bottom: two ¼ -20 threaded inserts
FCC compliance Class A
