DRO 100 Setup
7
Setup
The
SETUP
key lets you change the system parameters. The keys you use to change
setup parameters are different for one-axis and two-axis readouts. To move from
one parameter to the next, press the upper
ZERO key (the
SETUP
key for a single-axis
readout). After the last parameter, the same key ends the setup process and saves
any changes.
Some parameters may be set differently for each axis. For these parameters, the
display will indicate the axis by number. For example, linear error compensation
factors are indicated by LEC1 for the first axis and LEC2 for the second axis.
Some parameters have choices. Use the lower ZERO key to cycle through these
choices. If you have a single-axis readout, use the only ZERO key whenever the
lower ZERO key is referred to.
Display Resolution
The display resolution will be the same as the encoder resolution. If the job
tolerance is coarser than the encoder resolution (±0.005, for example), you can
adjust the display resolution so you won’t be tempted to waste time by machining
to a finer resolution. Use the lower
ZERO key to cycle through all the possible
choices. The choices available depend upon the resolution of your encoders.
