: On models with CMBS
Airbag System Components
Additional Information About Your Airbags
26
(1)
(2)
(3)
(4)
(5)
(8)
(7)
(6)
(4)
(5)
(10)
(9)
(9)
(6) Driver’s Seat Position Sensor
(7) Front Passenger’s Seat Weight Sensors
(8) Passenger Airbag Off Indicator
(9) Side Impact Sensors (First)
(10) Occupant Detection System (ODS) Sensors
(1) Driver’s Airbag
(2) Front Passenger’s Airbag
(3) Control Unit
(4) Front Seat Belt Tensioners/
Seat Belt e-pretensioners
(5) Side Airbags
2009 RL
