AiP-N series 16CH/9CH/4CH Manual

Chapter 9: Backup / Export

Backup methods explained:



DVD

– compatible with DVD+RW, DVD+R, DVD-RW, DVD-R



USB

– USB flash drives are removable, rewritable data storage devices with a Universal Serial Bus

(USB) interface



Temporary hard drive space

– save a backup clip to an area on the NVR hard drive that will not be

overwritten (only one file at a time). To access saved backup clip, use Backup Manager program or

web-based browser viewing

Different actions will provide a different export result:



Email will send a still image



USB will save a still image



Playback will take you to the selected event on screen

5. Recorded data

2. Time Frame

3. Unit selector

1. Channels

4. Backup bar

1. 16 bars represent 16 channels. 1 at the top

– 16 at the bottom

Colour code:

Yellow = alarm record

Blue = constant record

Green = no record

2. Time frame = year, month, day, hour, minute

3. Unit selector = the down arrow indicates desired selection

4. Back up bar = this is the orange bar that shows the range of your backup

Highlights green when back up section has been chosen

5. All recorded data = start, end, now box

File formats
