Vehicle power, Vehicle power 2-5 – Actron CP9175 OBD II AutoScanner User Manual
Page 23
AutoScanner® Specifications & Power Information
2-5
Vehicle Power
When using the OBDII Cable, the
power to the AutoScanner
®
comes
from the vehicle Data Link
Connector (DLC.)
1.Find Data Link
Connector on
Vehicle.
•Under dashboard
on driver side of
vehicle.
•If Data Link
Connector is not
located under the dashboard, a label should be there
telling where the connector can be found.
2.Remove Data Link
Connector Cover if
Required.
Diagnostic
Connector
Diagnostic
Connector
