Activeforever Teeter Hang Ups EZ-Up Inversion System - Manual (Page 3)

Gravity Boot
Hooks
Foot
Platform
CV Bar
Review all materials regarding inversion, Gravity Boots and your Teeter Hang Ups Inversion Table before inverting with
the CV Bar.
1. Preparing the Inversion Table:
• Confirm that the Main Shaft is adjusted to your proper height setting.
• Adjust the Foot Platform (up or down) to ensure the hooks are securly hooked to the CV bar with the bar touching or nearly
touching the base of the hook while the feet rest flat on the Foot Platform.
2. Mounting:
• While facing away from the table with your legs positioned on either side of the Main Shaft,
lift one foot so that Gravity Boot Hook wraps around the CV Bar.
• Slide the hook along the CV Bar until the foot is able to rest flat on the Foot Platform.
(See Figure 4)
• Repeat with the opposite foot.
Figure 4
Assembly & User Instructions LB-1007 Pg. 3
1 - Insert foot through
the Calf Loop.
5. 6.
buckle levers
4.
3. 1. 2. strap locks
Determine which is the RIGHT and LEFT boot: The hook on the RIGHT boot is labeled as such and the LEFT boot bears the
warning label.
Always wear the appropriate boot on each ankle - failure to do so may cause discomfort or equipment failure.
2 - Wrap the boots around
the ankle, positioning the
strap locks in front.
3 - Insert the end of the straps into
strap locks; DO NOT tighten yet.
6 - TO RELEASE: Lift up on the
buckle lever and push down on the
strap lock tab to release the strap.
4 - With the buckle levers still open, rotate
the hook to the front. Push down on the
boot so the base rests on top of your foot.
5 - Close the buckle levers, adjusting
the straps to fit your ankle. A snug (but
not tight) fit will be most comfortable.
USE INSTRUCTIONS
ASSEMBLING THE CV BAR (cont.) SECURING THE GRAVITY BOOTS
Setting the Foot Platform so that the hooks are not positioned securely around the
bar could cause you to fall during inversion, resulting in serious injury or death!
WARNING !
WARNING !
