6.0. USB Interface
The connection of the ACR100F to a computer through a USB port follows a USB Standard.
6.1. Communication Parameters
The ACR100F is connected to a computer through USB as specified in the USB Specification. The
ACR100F is working in high-speed mode, i.e. 480 Mbps, for the flash memory and USB 1.1 full-speed
mode for smart card interface.
Pin Signal Function
1 V
BUS
+5 V power supply for the reader
2 D- Differential signal transmits data between ACR100F and PC.
3 D+ Differential signal transmits data between ACR100F and PC.
4 GND Reference voltage level for power supply
6.2. Endpoints
The ACR100F uses the following endpoints to communicate with the host computer:
Control Endpoint 0 For setup and control purposes
Bulk OUT Endpoint 1 For the command to be sent from host to Mass Storage Interface
(data packet size is 64 bytes)
Bulk IN Endpoint 1 For response to be sent from Mass Storage Interface to host (data
packet size is 64 bytes)
Bulk OUT Endpoint 2 For command to be sent from host to CCID Interface (data packet
size is 16 bytes)
Bulk IN Endpoint 2 For response to be sent from CCID Interface to host (data packet
size is 16 bytes)
