Offset Field Size Value Description
40
dwFeatures
4
00010030h The Smart card reader supports the
following features:

Automatic ICC clock frequency
change according to
parameters

Automatic baud rate change
according to frequency and
FI,DI parameters

TPDU level exchange with the
smart card reader
44
dwMaxCCIDMessa
geLength
4
0000010Fh Maximum message length accepted by
the smart card reader is 271 bytes
48
bClassGetRespo
nse
1
00h
Insignificant for TPDU level exchanges
49 bClassEnvelope 1 00h Insignificant for TPDU level exchanges
50 wLCDLayout 2 0000h No LCD
52 bPINSupport 1 00h No PIN Verification
53
bMaxCCIDBusySl
ots
1
01h
Only 1 slot can be simultaneously busy
7.1. Command to the ACR100F (CCID)
In the normal operation, the ACR100F acts as a slave device with regard to the communication
between a computer and the reader. The communication is carried out in the form of successive
command-response exchanges. The computer transmits a command to the reader and receives a
response from the reader after the command has been executed. A new command can be transmitted
to the ACR100F only after the response to the previous command has been received.
There are two cases where the reader transmits data without having received a command from the
computer, namely, the Reset Message of the reader and the Card Status Message.
7.1.1. CCID Command Pipe Bulk-OUT Messages
The ACR100F shall follow the CCID Bulk-OUT Messages as specified in CCID section 4. In addition,
this specification defines some extended commands for operating additional features. This section
lists the CCID Bulk-OUT Messages to be supported by ACR100F.
7.1.1.1. PC_to_RDR_IccPowerOn
Activate the card slot and return ATR from the card.
Offset Field Size Value Description
0
bMessageTy
pe
1
62h
1
dwLength
4
00000000
h
Size of extra bytes of this message
2 bSlot 1 Identifies the slot number for this command
5 bSeq 1 Sequence number for command
6
bPowerSele
ct
1
Voltage that is applied to the ICC
00h – Automatic Voltage Selection
01h – 5 volts
02h – 3 volts
7 abRFU 2 Reserved for future use
The response to this message is the RDR_to_PC_DataBlock message and the data returned is the
Answer To Reset (ATR) data.
