7.1.2.2.
RDR_to_PC_SlotStatus
This message is sent by the smart card reader in response to PC_to_RDR_IccPowerOff,
PC_to_RDR_GetSlotStatus, PC_to_RDR_Abort messages and Class specific ABORT request.
Offset Field
Size Value
Description
0
bMessageTy
pe
1
81h
1
dwLength
4
0000000
0h
Size of extra bytes of this message
5
bSlot
1
Same value as in Bulk-OUT message
6
bSeq
1
Same value as in Bulk-OUT message
7
bStatus
1
Slot status register as defined in CCID section
4.2.1
8
bError
1
Slot error register as defined in CCID section
4.2.1 and this specification section 5.2.8
9
bClockStat
us
1
value =
00h Clock running
01h Clock stopped in state L
02h Clock stopped in state H
03h Clock stopped in an unknown state
All other values are RFU.
