ACR100F (CCID) Reference Manual
Version 3.00
[email protected]
www.acs.com.hk
7.1.2.3. RDR_to_PC_Parameters
This message is sent by the smart card reader in response to PC_to_RDR_GetParameters,
PC_to_RDR_ResetParameters and PC_to_RDR_SetParameters messages.
Offset Field Siz
e Value Description
0 bMessageType 1 82h
1 dwLength 4 Size of extra bytes of this message
5 bSlot 1 Same value as in Bulk-OUT message
6 bSeq 1 Same value as in Bulk-OUT message
7
bStatus
1
Slot status register as defined in CCID section
4.2.1
8
bError
1
Slot error register as defined in CCID section
4.2.1 and this specification section 5.2.8
9
bProtocolNum
1
Specifies what protocol data structure follows.
00h = Structure for protocol T=0
01h = Structure for protocol T=1
The following values are reserved for future
use.
80h = Structure for 2-wire protocol
81h = Structure for 3-wire protocol
82h = Structure for I2C protocol
10
abProtocolData
Structure Byt
e
arra
y
Protocol Data Structure as summarized in
section 5.2.3.
7.1.3. Commands Accessed via PC_to_RDR_XfrBlock
7.1.3.1. GET_READER_INFORMATION
This command returns relevant information about the particular smart card reader model and the
current operating status such as the firmware revision number, the maximum data length of a
command and response, the supported card types, and whether a card is inserted and powered up or
not.
Note: This command can only be used after the logical smart card reader communication has
been established using the SCardConnect( ) API. For details of ScardConnect( ) API,
please refer to PC/SC specification.
Pseudo-APDU
CLA INS P1 P2 Lc
FF
H
09
H
00
H
00
H
10
H
Command format (abData field in the PC_to_RDR_XfrBlock)
Response data format (abData field in the RDR_to_PC_DataBlock)
FIRMWARE MAX
_C MAX
_R C_TY
PE C_SE
L C_ST
AT
