06-0383-000 Rev. C
timeQplus Connectivity Diagrams*
timeQplus Diagramas de conectividad
Diagrammes de connectivité de timeQplus
RS232 Directo
72-0207-000
USB Cable
(Included)
Power
Jack
USB Mini-B
(select Models)
Ethernet,
RS232
Connector
Electrico
Jack
délectricité
USB cable
(Incluido)
USB Câble
(Inclus)
USB Directo
Bottom View
of Terminal
Puerto de
Comunicaciones
Image de la
basse du terminal
9-Pin Female
D-Connector
RJ45 Connector
Ethernet,
RS232
Bottom View
of Terminal
Puerto de
Comunicaciones
Image de la
basse du terminal
Power
Jack
Connector
Electrico
Jack
délectricité
RJ45 Conector
RJ 45 Connecteur
Conector
Macho 9-Polo
9 Goupilles
D-Connecteurs
féminine
RS232 Cable
(Incluido)
RS232 Câble
(Inclus)
P/N 72-0208-000
RS232 Cable
(Included)
USB Mini-B
(select Models)
* Hardware manual available on the CD and online at www.support.acroprint.com
1) Connect Directly to PC - via USB cable
(available only on timeQplus Biometric & Proximity models)
2) Connect Directly to PC - via RS232 cable
(available only on timeQplus Biometric & Proximity models)
