Timeqplus connectivity diagrams, 3) ethernet direct, Ethernet directo – Acroprint timeQplus v3 Connectivity Diagrams (software version 3.x) User Manual
Page 2

timeQplus Connectivity Diagrams
timeQplus Diagramas de conectividad
Diagrammes de connectivité de timeQplus
4) Connection to an Existing Local Area Ethernet Network
Connexion à un réseau existant Ethernet
Conneccion a su Existente Red de Ethernet
Plug Into an
Existing
Local Area
Ethernet
Network
Power
Jack
USB
Mini-B
Bottom View of
TQ600 Terminal
Puerto de
Comunicaciones
Image de la
basse du terminal
TQ600
Connector
Electrico
Jack
délectricité
Ethernet,
RS232
Conectar a su
red Ethernet
existente
Connecter à un
réseau existant
Ethernet
Max. Length = 325 ft.
P/N 72-0205-000
1.5m Standard Ethernet Cable
(Included)
distancia maxima = 100m/325 ft.
1.5m Cable Ethernet Estqandar
(Incluido)
longueur max. = 325 pieds/99m
1.5m Câble Standard Ethernet
(Inclus)
Power
Jack
Ethernet,
RS232
USB
Mini-B
Connector
Electrico
Jack
délectricité
Ethernet Crossover Cable
Max. Length = 325 ft.
(Not Included)
Cable Cruzado Ethernet
(comprar en su tienda local de Electronical)
3) Ethernet Direct
Ethernet Directo
Bottom View of
TQ600 Terminal
Puerto de
Comunicaciones
Image de la
basse du terminal
TQ600
distancia maxima = 100m/325 ft.
Câble inversé Ethernet
(achetez le dun magasin des ordinateurs)
longueur max. = 325 pieds/99mètres
