ACR&Artex Float-Free 406 Memory Capsule User Manual
Page 7
Y1-03-0199 Rev. E
4
Electronic Housing
Hydrostatic Release Unit
Data Transfer Cable
Cutter Mechanism
(Activation Trigger)
Memory Capsule Antenna
Warning Plate
(not shown)
Cat 5 Cable
(Located behind
bracket shield)
Strobe Light
Battery Compartment
Data Transfer into
Memory Capsule
Memory Capsule
Ejector Spring
Data Transfer Junction Box
Cutter Mechanism
(Cable Slot)
Float Free Memory Capsule Components
Front view
Figure 1
Water Sensor
Deactivation Magnet
SeaShelter2™ Bracket
Electronic
Housing
