Y1-03-0240C 18
APPENDIX B - TECHNICAL SPECIFICATIONS
GENERAL/ ENVIRONMENTAL
Beacon size (without
antenna)
17.7 H X 10.67 W X 9.09 D cm (6.97 X 4.2 X
3.58 in)
Beacon weight 592 g (20.88 oz)
Beacon material High impact UV resistant polymer
Color ACR-
Treuse™ (high visibility yellow)
Waterproof Tested to 10 min @10 m (33 ft), exceeds
RTCM standard
Buoyant Yes
Deployment Manual
BATTERY
Operational life 48 hours minimum @-20ºC (-4ºF) (Class 2)
Battery type and
replacement interval LiMnO
2
5 years from date beacon placed in service, or
after use in an emergency not to exceed
battery expiry
Operating temperatures
Storage temperatures -20º C to +55º C (-4º F to +131º F) (Class 2)
-30º C to +70º C (-22º F to +158º F) (Class 2)
406 MHz TRANSMITTER
Frequency 406.037 MHz
Power output 5 W
Digital message format User protocol
121.5 MHz TRANSMITTER
Frequency 121.5 MHz
Power output 25 mW PEP
Modulation type AM (3K20A3X)
LED STROBE
Light color White
Output power 1 cd (effective candela)
Flash rate 20-30/ min
Range 360º visibility
GENERAL
Accessories

Mounting bracket, ACR P/N 9502
Approvals

Cospas-Sarsat certificate #189

Meets Class 3 (AS/NZ 4280.1) EPIRB
NOTE: For complete information regarding beacon type approvals, please
visit ACR’s website at
www.acrartex.com
