PC 6410
10.2” Fanless Panel PC
4.9.7 LCD POWER SELECT JUMPER
Jumper Label: J_VLVDS1
Jumper Type:
3-pin header
Jumper Settings:See Table 4-5
Jumper Location:
See Figure 4-8
The LCD Power Select jumper sets the power setting of the LCD panel.
Setting
Description
Short 1-2 +3.3V
Short 2-3 +5V
The LCD Power Select jumper location is shown in Figure 4-8.
