PC 6410
10.2” Fanless Panel PC
4.3 PREINSTALLED COMPONENTS
The following components are all preinstalled.
"
Motherboard
"
TFT LCD screen
"
1.0 GB DDR2 memory module
"
Resistive type touch screen
"
Wireless LAN module
"
Bluetooth module
"
AT/ATX power switch
Preinstalled customizations may include the following.
"
Different DDR2 memory module
"
Hard disk drive (PC12A/PC15A/AE only) Component installation is described in
the following sections.
4.4 INSTALLATION AND CONFIGURATION STEPS
The following installation steps must be followed.
Step 1: Unpack the flat panel PC.
Step 2: Install a CF card
Step 3: Install an HDD (PC6412 and PC6415 only)
Step 4: Configure the system
Step 5: Connect peripheral devices to the bottom panel of the flat panel PC
Step 6: Mount the flat panel PC
Step 7: Install faceplate onto the flat panel PC
