15. FP1 :
(2.0mm Pitch 2X5 Pin Header), Front panel connector.
Signal Name
Pin#
Pin#
Signal Name
HD LED+
1
2
POWER LED+
HD LED-
3
4
POWER LED-
Ground
5
6
PWR_ON
RESET+
7
8
Ground
WAN LED-
9
10
WAN LED+
Pin1-3:
HDD LED, They are used to connect hard disk activity LED. The LED
blinks when the hard disk is reading or writing data.
Pin2-4:
POWER LED, They are used to connect power LED. W hen the system
is powered on or under S0/S1 state, the LED is normally on; when the
system is under S4/S5 state, the LED is off.
Pin5-6:
POWER on/off Button, They are used to connect power switch button.
The two pins are disconnected under normal condition. You may short
them temporarily to realize system startup & shutdown or awaken the
system from sleep state.
Pin7-8:
RESET Button, They are used to connect reset button. The two pins
are dis-connected under normal condition. You may short them
temporarily to realize system reset.
Pin9-10:
WAN LED, They are used to connect WAN LED.
Note:
When connecting LEDs, pay special attention to the signal polarity.
Make sure that
the connector
pins have a one-to-one
correspondence with chassis wiring, or it may cause boot up failure.
