Acer Aspire 8943G - Manual (Page 12)

10
English
Base view
1
2
3
4
5
7
8
6
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Sub woofer Emits low frequency sound output.
3 Battery release latch Releases the battery for removal.
4 Memory compartment Houses the computer's main memory.
5 Hard disk bay-Main Houses the computer's hard disk (secured
with screws).
6 Speakers Deliver stereo audio output.
7 Hard disk bay-
Secondary
Houses the computer's hard disk (secured
with screws) (for certain models only).
8 Battery lock Locks the battery in position.
7 RF-in port Accepts input signals from digital TV-
tuner devices.
(only for certain models)
8 DC-in jack Connects to an AC adapter.
# Icon Item Description
