10
English
Base view
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
3 Hard disk bay Houses the computer's hard disk (secured
with screws).
Memory compartment Houses the computer's main memory.
4 Acer DASP (Disk Anti-
Shock Protection) Protects the hard disk from shocks and
bumps.
5 Battery release latch Releases the battery for removal.
Environment • Temperature:
• Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
• Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%
1
2
3
4
5
