Base view – Acer W700P User Manual
Page 30
28 - Your Acer notebook tour
Base view
#
Icon
Item
Description
1
Battery release
latch
Releases the battery for removal. Insert
a suitable tool and slide to release.
2
Memory
compartment
Houses the computer's main memory.
Hard disk bay
Houses the computer's hard disk.
3
Battery bay
Houses the computer's battery pack.
4
Ventilation and
cooling fan
Allows the computer to stay cool.
Do not cover or obstruct the openings.
