Acer TravelMate 4750ZG - Manual (Page 11)

9
Eng
lis
h
Base view
Environment
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
3 Hard disk bay Houses the computer's hard disk (secured
with screws).
Memory
compartment Houses the computer's main memory.
4 Battery release latch Releases the battery for removal.
• Temperature:
•
Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
• Humidity (non-condensing):
•
Operating: 20% to 80%
• Non-operating: 20% to 80%
2
1
3
4
