Setting configurations
The RAID (level 0 or 5) is set manually by placing jumper heads on the ten jumper pins on the
rear of the RAID box.
RAID 0 configuration
1. Make sure the power is turned off.
2. Place two jumper caps over the top
pairs of RAID configuration jumper
pins.
RAID 5 configuration
1. Make sure the power is turned off.
2. Make sure the ten RAID configuration
jumper pins are clear of any jumper
caps.
