The following details the information of digit LED display:
DMX signal
Displayed Value Function
001-100 The driven pixels of AL-Pixel
The device is for indoor use only, don't expose it to rain or moisture.
SAFETY INFORMATION
The ground connection should be essential for this unit.
Do not make any inflammable liquids, water or metal objects enter the unit.
To prevent or reduce the risk of electric shock, DO NOT OPEN THE TOP COVER.
There are no user serviceable parts inside this unit. Do not attempt any repairs yourself.
Should you experience any problem during use, please contact your local dealer immediately.
Do not insert objects into the ventilation area.
Read this manual carefully and thoroughly before powering or installing the unit, and follow the safety
precautions listed below and observe all warnings in this manual and printed on the unit:
Disconnect the device from AC power before configuring the system and when not in use.
Make sure your AL-Pixel-Driver has connected with a suitable source of AC power before operating.
This unit must be operated by adults, do not allow children to play with it.
-Page 2-
OPERATION GUIDE
For example, connect 2 groups of AL-Pixel to a AL-Pixel-Driver, each group having 50 pixels of AL-
Pixel. You need to tap the UP/DOWN button to set the displayed value to 50. For Output1, the
starting DMX address is set to 1 automatically. For Output2, the driven pixels are 50 and the starting
DMX address is 50x3+1=151.
Since one output can control up to 100 pixels, a AL-Pixel-Driver can control maximum 200 pixels.
NOTE: The driven pixel of Output 1 is always 100 and users cannot change it.
TECHNICAL SPECIFICATION
Power Input
Data Input
Data Output
Fuse
Housing
IP Rating
Control
Listing
Operation Temperature
Storage Temperature
Dimension
Weight
Output Voltage:
110-120VAC(3.2A)/220-240VAC(1.6A), 50/60Hz
9VDC, 6A/Output, total 12A max.
12VDC, 6A/Output, total 12A max.
15VDC, 6A/Output, total 10A max.
18VDC, 6A/Output, total 8A max.
24VDC, 6A/Output, total 6A max.
3-Pin XLR male connector or green terminal
3-Pin XLR female connector or green terminal
T3.15A, 250V, 5x20mm
IP 20
DMX-512(1990)/DMX-1000K
CE certified
0 degC to + 40 degC
-20 degC to + 70 degC
328(L) x 144(W) x 70(H)mm
Metal sheet with powder painting
Output 4-Pin terminal (2pcs)
2.2kg
