-2-
1. Take out the AL-DIMMER-1 HP and the screw driver from packing.
2. Use the screw driver to prize up the rear panel of AL-DIMMER-1 HP with the proper strength, as the following
figures.
3. Use the screw driver to move the 2 way dip-switch to on or off for output current option.
4. After the current was selected, to reassemble the rear panel.
2 way dip-switch
ON
OFF 1 2
After the reassembly is completed, to connect the AL-DIMMER-1 HP to the power source for use.
Reassembly
Current
350mA
500mA
500mA
700mA Off
2
Off
1
Off On
On Off
On On
While the one of the built-in Dipswitch is "On", the AL-DIMMER-1 HP 500mA current, the one of the current
indicator on the front panel will light, the other black out.
will output
While both the built-in Dipswitch are "Off", the AL-DIMMER-1 HP will output 350mA current, both the current
indicators on
. the front panel will black out
700mA
the front panel will light
While both the built-in Dipswitch are "On", the AL-DIMMER-1 HP will output current, both the current
indicators on .
