28 en FCS-320-TP1 | FCS-320-TP2 | FCS-320-TT1 | FCS-320-TT2
F.01U.130.927 | 2.0 | 2010.12 Bosch Sicherheitssysteme GmbH
1. Check the system after installation using the FAS-ASD-DIAG Diagnostic Software.
2. The unit must be operated for at least 30 min prior to the airflow being initialized to bring
it up to operating temperature.
3. To initialize the connected pipe system, press the S2 flow-init button (see Figure 5,
Page 5) on the detector module concerned until the green operating LED on the unit
starts to flash. Initialization is complete after approx. 10 seconds. Following successful
initialization, the operating LED lights up permanently.
4. No further modifications may be made to the pipe system during or after initialization.
The unit's fan voltage must also remain unchanged following initialization. Otherwise, the
initialization procedure must be repeated.
Troubleshooting Using Flash Codes
Malfunctions and unit statuses are indicated via the flash codes of the detector module LEDs:
Technical data
Flash code of detector module LEDs
1 flash
Airflow initialization (flow-init) active
2 x flashes Airflow too small (obstruction)
3 x flashes Airflow too great (break)
4 x flashes Unit upload (approx. 2 minutes)
Permanently lit Hardware defect in the detector module
LED flash code on the motherboard (LED1/LED2)
1 flash Error: internal voltage monitoring 1
2 flashes Error: internal voltage monitoring 2
3 flashes Error: fan voltage monitoring
4 flashes Error: air pressure correction voltage monitoring
5 flashes Software error
6 flashes Internal error 1
7 flashes Internal error 2
8 flashes Unit upload (approx. 2 min)
Power supply 14 V DC to 30 V DC
Rated supply voltage 24 V DC
Max. current consumption (at 24 V) FCS-320
-TP1/-TT1 FCS-320
-TP2/-TT2
- Starting current 6.9 V (without reset board) 300/300 mA 320/330 mA
- Starting current 9 V (without reset board) 300/300 mA 320/330 mA
- In standby, fan voltage 6.9 V (without reset board) 200/200 mA 220/230 mA
- In standby, fan voltage 9 V (without reset board) 275/260 mA 295/310 mA
- On alarm, fan voltage 6.9 V (without reset board) 210/230 mA 240/290 mA
- On alarm, fan voltage 9 V (without reset board) 285/290 mA 315/370 mA
Reset board current consumption Max. 20 mA
Max. wire gauge 2.5 mm 2
Housing material Plastic (ABS)
Housing color Papyrus white, RAL 9018
Protection category according to EN 60529 IP 20
Permissible temperature range
-
FCS-320 series Aspirating Smoke Detector -20 °C to +60 °C
- PVC pipe system -10 °C to +60 °C
- ABS pipe system -40 °C to +80 °C
Permissible relative humidity (non-condensing) 10 to 95%
Sound power level 45 dB(A)
Life cycle of the fan (12 V) 43,500 hrs at 24 °C
