Installation
FCS-320-TP1 and FCS-320-TP2 System Overview
See Figure 1, Page 4
FCS-320-TT1 and FCS-320-TT2 System Overview
See Figure 2, Page 4
Jumper Assignment
See Figure 4, Page 5
CAUTION!
Installation must only be performed by authorized and specialized personnel!Switch off the
unit before carrying out the following work.Do not connect or disconnect the detector module
while switched on!
1 Operating LED
2 Alarm LED for detector module 1
3 Alarm LED for detector module 2 (for FCS-320-TP2 only)
4 Collective fault LED
5 Pre-punched cable entries for connection to the fire panel and power supply
(input/output)
6 Pipe system 1 connection
7 Pipe system 2 connection (required for FCS-320-TP2 only)
8 Connection for air return pipe
1 Operating LED
2 Collective fault LED
3 Info alarm LED for detector module 1
4 Pre-alarm LED for detector module 1
5 Main alarm LED for detector module 1
6 Smoke level display in ten levels, detector module 1
7 Info alarm LED for detector module 2 (for FCS-320-TT2 only)
8 Pre-alarm LED for detector module 2 (for FCS-320-TT2 only)
9 Main alarm LED for detector module 2 (for FCS-320-TT2 only)
10 Smoke level display in ten levels, detector module 2 (for FCS-320-TT2 only)
11 Pre-punched cable entries for connection to the fire panel and power supply (input/
output)
12 Pipe system 1 connection
13 Pipe system 2 connection (required for FCS-320-TT2 only)
14 Connection for air return pipe
Jumper JU1: fan voltage Pin 1+2
6.9 V Bypassed
9 V Open
Jumper JU2: collective fault contact for detector module 1 Pin 1+2 Pin 2+3
NC contact Bypassed Open
NO contact Open Bypassed
Jumper JU3: collective fault contact for detector module 2 Pin 1+2 Pin 2+3
NC contact Bypassed Open
NO contact Open Bypassed
Jumper JU4: number of detector modules Pin 1+2
1 detector module Bypassed
2 detector modules Open
