MDA200 Basics
1
Computer talk button
2
Desk phone talk button
3
USB headset/USB wireless adapter port
(headset and adapter not included)
4
USB cable (connect to computer)
5
Handset lifter/EHS cable jack
6
Telephone interface cable jack
7
Power jack
8
Configuration slide switch
9
Listening volume dial
10
Speaking volume dial
5
7
8
4
BACK
FRONT/TOP
3
6
BOTTOM
4
10
9
1
2
