9
Output data
Name of item Header Output data (ASCII code)
Pattern
Counting mode Weight mode
Control data {0 Fix to 16 2 Bytes fi xed ✓ ✓
Control data ˜0 Fix to 1 1 Bytes fi xed ✓ ✓
Model MO “KP-601” 8 Bytes fi xed ✓ ✓
Displayed weight Wg x.xxx ~ xxx.xxx 5–7 bytes ✓ ✓
Tare weight Pt x.xxx ~ xxx.xxx 5–7 bytes ✓ ✓
Pieces Pi xxxx 1–5 bytes ✓ —
Note:
• The data are divided with commas (,) for each data.
• The terminator (end of the data) is CR (ASCII code 0DH), LF (ASCII code 0AH).
• The control data for the items 1–2 are for expansion. They are not used presently so the
receiving side can ignore them.
• Because of its specifi cations, the scale will output an irrelevant signal when it’s turned off. Make
sure you ignore this signal and do not import it.
• The weight data are shown only in grams.
[Output data]
K
W
Displayed Weight Tare Weight Pieces
g P t P i
P 6 0 1
