2.8 Maintenance
# When carrying out any work, disconnect
all poles from the mains supply.
# Check the protective anode for the first
time after two years of operation, and
replace it if necessary; to do this, the
heating element must be removed. After
replacing the protective anode, the
qualified installer will decide at what
intervals further checks are to be carried
out.
Transitional resistance between protective
anode and container connection nozzle
max. 1.0
".
# Check the safety group regularly.
Other instructions regarding the unit:
#
Only remove limescale from the element
after disassembly. Do not treat the
container surface and protective anode
with descaling products.
# Safety device:
Regulator-limiter combination immersion
depths
H :
a Limiter sensor
b Regulator sensor
# Draining the storage water heater
cylinder: Before draining the cylinder,
disconnect the unit from the mains supply.
– Close the isolating valve in the cold
water feed line.
– Open the hot water fittings fully at all
draw-off points.
– Unscrew the cap from the drainage
nozzle ( A 9).
Hot water may come out during
draining.
# The corrosion protection resistor I on
the insulating plate must not be damaged
or removed during servicing work. When
replacing the corrosion protection resistor
the assembly is to be re-established in the
correct manner.
a Copper heating element
b Insulating plate
c Pressure plate
d Corrosion protection resistor
Fault Cause Rectification
No hot water – Safety temperature limiter has tripped. – Rectify cause of fault. Replace regulator-
limiter combination .
6. Fault rectification
- Qualified Installer
Table 3
Table 2
– Heating element defective . – Replace heating element .
5. Fault rectification
- Users
No hot water – No voltage. – Check fuses in the house installation.
– Dirt or limescale in the perlators in the
fittings or shower heads.
Fault Cause Rectification
– Clean and/or descale the outlet fittings. No flow rate.
Please help us to protect the environment by
disposing of the packaging in accordance with
the national regulations for waste processing.
4. Environment and
recycling
3. Guarantee
For guarantees please refer to the pespective
terms and conditions of supply for your
country.
The installation, electrical connection
and first operation of this appliance
should be carried out by a qualified
installer.
The company does not accept liability for
failure of any goods supplied which accor-
dance with the manufacturer's instructions.
2.9 Special accessories
# Hanging bracket end covers
Part No: 15 04 28
N (a, 2 pieces in
packet) for the range of hanging brackets:
#
SH 50 A, SH 80 A, SH 100 A
Order 1 x Part No: 15 04 28
# SH 120 A, SH 150 A
Order 2 x Part No: 15 04 28
# Universal wall-hanging bracket O
Part No: 15 48 28
Variable 3 point hanging bracket (a) used
when replacing old style unit. Hanging fish-
plate supplied, can be used (b).
# Ceiling mounting bracket P
1 x Part No: 15 48 28 (a) and
1 x Part No: 15 48 27 (b)
Fixing to the ceiling is possible when used
in combination with the universal wall
hanging bracket.
