Milwaukee DD 3 -152 - Manual (Page 32)

29
English
GB GB
English
TECHNICAL DATA
Diamond Drill
DD3-152
(110-120 V)
DD3-152
(220-240 V)
Production code 4315 31 01...
... 000001-999999
4280 01 01...
... 000001-999999
Rated input 1700 W 1900 W
No-load speed 1st gear 0 -10000 min -1 0 -1050 min -1
No-load speed 2nd gear 0 -21000 min -1 0 -2400 min -1
No-load speed 3rd gear 0 -3900 min -1 0 -4700 min -1
Drilling using the drill stand:
Drilling capacity max. in concrete, 1st/2nd/3rd gear
152/62/32 mm 152/62/32 mm
Hanheld drilling:
Drilling capacity max.
in concrete, 2nd/3rd gear
in brick and tile, 1st/2nd/3rd gear
62/32 mm
200/112/62 mm
62/32 mm
200/112/62 mm
Tool reception
1
/
2
“ / 1
1
/
4
“ UNC
1
/
2
“ / 1
1
/
4
“ UNC
Weight according EPTA-Procedure 01/2003 6,5 kg 6,5 kg
Weight + DR 152 T 16,5 kg 16,5 kg
Safety class II II
Degree of protection IP 20 IP 20
Noise/Vibration Information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K=3dB(A))
Sound power level (K=3dB(A))
84,0 dB (A)
95,0 dB (A)
84,0 dB (A)
95,0 dB (A)
Measured values determined according to EN 61 029.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K=3dB(A))
Sound power level (K=3dB(A))
Wear ear protectors!
85,1 dB (A)
97,0 dB (A)
85,1 dB (A)
97,0 dB (A)
Total vibration values (vector sum in the three axes) determined according to EN 60745.
Vibration emission value a
h
Drilling into concrete, wet
Uncertainty K =
14,1 m/s 2
2,0 m/s 2
14,1 m/s 2
2,0 m/s 2
Drilling into brick and tile, dry
Uncertainty K =
16,3 m/s 2
2,0 m/s 2
16,3 m/s 2
2,0 m/s 2
Drill Stand DR 152 T
Length of the column 1000 mm
Drilling capacity max. 152 mm
Inclination 0 - 45 °
Weight 10 kg
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and may be
used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission may differ. This may significantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is running but not
actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories, keep the hands
warm, organisation of work patterns.
