Edimax Technology CV-7428nS - Manual (Page 41)

41
4. Click on “Ethernet” in the left panel and then click the drop down arrow for
the menu labeled “Configure IPv4” in the right panel. From the drop down
menu, select “Using DHCP” and then click “Apply”.
IV-1-2. How to modify the IP address of your PC or Macintosh
Please follow the instructions appropriate for your operating system. In the
following examples we use the IP address 192.168.9.20 though you can use
any IP address in the range 192.168.9.x (x = 3 – 254) in order to access the
browser based configuration interface.
Note: Please make a note of your static IP before
you change it. This is for your convenience if you
wish to modify the IP address of the wireless bridge
in future. To modify the IP address of the wireless
bridge, please refer to
III-5. Administrator.
IV-1-2-1. Windows XP
1. Click the “Start” button (it should be located in the lower-left corner of your
computer), then click “Control Panel”. Double-click the “Network and
Internet Connections” icon, click “Network Connections”, and then
double-click “Local Area Connection”. The “Local Area Connection Status”
window will then appear, click “Properties”.
