Here are descriptions of every setup item:
Item Name Description
Enable QoS Check this box to enable QoS function, uncheck
it to disable QoS.
Total Download
Bandwidth You can set the limit of total download
bandwidth in kbits. To disable download
bandwidth limitation, input ‘0’ here.
Total Upload
Bandwidth You can set the limit of total upload bandwidth
in kbits. To disable upload bandwidth limitation,
input ‘0’ here.
Rule Name Input a name for this QoS rule for identification
purpose. This name should be unique and not
the same with others.
Bandwidth Set the speed limitation for this QoS rule:
(1) (2) (3)
(1) Please select Download / Upload for the
direction of data for this QoS rule first,
(2) Input the data rate for this QoS rule,
(3) and select Guarantee (provides a
