48
The following table describes the parameters of this page:
Field Description
Virtual Circuit
Select a virtual circuit from the drop-list. Click PVCs
Summary to view eight PVCs (from PVC0 to PVC7), and
only PVC0 status is activated by default.
Status
You can select Activated or Deactivated for currently
selected virtual circuit.
VPI
The virtual path between two points in an ATM
network, ranging from 0 to 255.
VCI
The virtual channel between two points in an ATM
network, ranging from 1 to 65535.
ATM QoS Select the Quality of Service types for this Virtual Circuit.
The ATM QoS types include CBR (Constant Bit Rate), VBR
(Variable Bit Rate) and UBR (Unspecified Bit Rate). These
QoS types are all controlled by the parameters specified
below, including PCR, SCR and MBS. You can choose
