44
The following table describes the parameters in this page:
Field Description
VPI
Virtual path identifier (VPI) is the virtual path between two
points in an ATM network. Its valid value is between 0 and
255. Enter the correct VPI provided by your ISP. By default,
VPI is set to 8.
VCI
Virtual channel identifier (VCI) is the virtual channel between
two points in an ATM network. Its valid value is between 1
and 65535. Enter the correct VCI provided by your ISP. By
default, VCI is set to 35.
Connection
Type You can select LLC or VC-Mux. In this example, the
encapsulation mode is set to 1483 Bridged IP LLC.
5.3.3. Dynamic IP Address
For configuration method, please refer to that of Auto setup by ISP list
Select Auto setup by ISP list, click NEXT, and the page as shown in the
following figure appears.
