Festool CTM 48 E-LE-AC CLEANTEX - Manual (Page 15)

CTM
15
GB
5 Intended use
Mobile dust extractor suitable for
– Extracting dust up to 0,1 mg/m³ according to dust
class 'M', including wood and paint dust,
– Extracting water,
– Increased loads during commercial use,
according to IEC/EN 60335-2-69.
The user is liable for improper or non-intend-
ed use.
6 Operation
6.1 Initial operation
 Open the locking clips [2-2] and remove the top
section of the machine [2-1].
 Remove the accessories from the dust container
[2-3] and the packaging!
 Insert a filter or disposal bag in the dirt trap (see
chapter 7.7 and 7.8).
 Replace the top section [2-1] and close the lock-
ing clips [2-2].
 Attach the cable holder to the rear of the mobile
dust extractor (see Fig. [3]).
 Connect the suction hose to the machine.
6.2 Switch on/off
 Insert the plug into an earthed socket.
The switch [1-11] serves as an on/off switch.
Switch position "0"
Appliance socket [1-4] is disconnected from the
power, mobile dust extractor is switched off.
"MAN" switch position
Appliance socket [1-4] is connected to the power, the
mobile dust extractor starts.
"Auto" switch position
Appliance socket [1-4] is connected to the power, the
mobile dust extractor starts when the connected tool
is switched on.
7 Settings
7.1 Adjusting the hose diameter
 Adjust the hose diameter adjuster [1-9] to match
the diameter of the connected hose.
 The monitoring devices will measure the air
speed in the extractor hose correctly as a result
(see chapter 7.9).
7.2 Connecting electric power tools
 Connect the electric power tool to the appliance
socket [1-4].
7.3 Connecting pneumatic tools
Automatic on/off switch for air tools (CTM 36 E LE,
CTM 36 E LE AC, CTM 48 E LE, CTM 48 E LE AC or
accessories)
with compressed air module in module slot [1-3]
Recommendation:
– Attachment of service unit VE (495886): com-
pressed air filtered and lubricated
– Use of IAS system with IAS connector (454757) for
Festool air tools
Requirement: tool with operating pressure of 6 bar!
7.4 Adjusting the suction power
 Use the rotary knob [1-10].
7.5 Applying the brake
Folding out the black brake lever [1-15] prevents
the mobile dust extractor from rolling. To achieve
this, lift the front end of the mobile dust extractor
slightly and push the black brake lever downwards
until it latches into place. Push the green lever [1-
14] again to release.
WARNING
Unauthorised voltage or frequency!
Risk of accidents
 Observe the specifications on the machine’s
name plate.
 Observe country-specific regulations.
WARNING
Risk of injury from tools starting up unexpectedly
 Before setting the switch to the "AUTO" or
"MAN" position, make sure that the connected
tool is switched off.
WARNING
Risk of injury
 Observe the maximum appliance socket con-
nected load (see chapter "Technical data")
 Switch off the electric power tool.
WARNING
Risk of injury
 Switch off the air tool.
