Xerox 490/980 Color Continuous Feed Printing System

Hints and Tips

Hints and Tips User Guide

1-15

Printer Manager/
Consumables/Kit B
(Black) Replace

Re-number to step 6

Same change for
all Kit B colors.

Printer Manager/
Consumables/Kit B
(Black) Replace

8. Hold the Cleaner
Blade Knob (d) with
your left hand, pull it
slightly frontward, and
remove the knob.

Re-number to step 7 and
re-write as follows:
7. Pull the Cleaner Bade
Knob (d) slightly forward
and remove.

Same change for
all Kit B colors.

Printer Manager/
Consumables/Kit B
(Black) Replace

9. Wrap up the Cleaner
Blade with the collector
bag (f). Pull out the bag
to take out the Cleaner
Blade into the bag.

Re-number to step 8 and
re-write as follows:
8. Insert the Cleaner
Blade into the collector
bag (f). Pull out the bag
removing the Cleaner
Blade.

Same change for
all Kit B colors.

Printer Manager/
Consumables/Kit B
(Black) Replace

10. Attach the knob to
the new Cleaner Blade
(b), insert it along the
guide, and tighten the
thumb nut.

Re-number to Step 9 and
re-write as follows:
9. Attach the knob to the
new Cleaner Blade (b) by
inserting along the guide
and tighten the thumb
nut.

Same changes for
all Kit B colors

Printer Manager/
Consumables/Kit B
(Black) Replace

, then cover

Re-number to step 10
and change:
and
door

Same change for
all Kit B colors

Printer Manager/
Consumables/Transfer
Roller Cleaner (Black)
Replace

1: Open the printer 1
top cover.

Delete “1”
1. Open the printer top
cover.

Printer Manager/
Consumables/Transfer
Roller Cleaner (Black)
Replace

3: Holding the knobs (b),
slightly move the
Transfer Roller Cleaner
frontward (1), and then
lift it up (2).

Step 3: Holding the

handles

(b), slightly

move the Transfer Roller
Cleaner forward (1), and

lift up

(2).

Same change for
all Transfer Roller
Cleaner colors.

Printer Manager/
Consumables/Transfer
Roller Cleaner (Black)
Replace

5. Holding the knobs (b)
on the new Transfer
Roller Cleaner, install it
on the machine (1), (2).

Step 5: Holding the

handles (b), install the
new Transfer Roller
Cleaner in the machine
(1) and push toward the
rear of the machine (2).

Add a line space, and
add a caution symbol
for the following
statement:

Be careful

not to touch damage the
guide roller on the new
Transfer Roller Cleaner.

Same change for
all Transfer Roller
Cleaner colors.

Maintenance/Software/
Software Info

Remove LCDS
information

Path from Main Menu

Present

Required Change

Comments
