5
P-660RU-Tx v2 Quick Start Guide
"
Do NOT connect the same computer to both the
USB and ETHERNET ports on the P-660RU-Tx
v2.
1 USB: Connect the provided USB cable to the P-660RU-Tx
v2’s USB port.
2 DSL: Use the gray telephone wire to connect your P-
660RU-Tx v2’s DSL port to a telephone jack (or to a
splitter, if one is already installed).
3 POWER: Use the power adaptor provided with your P-
660RU-Tx v2 to connect an appropriate power source to
the POWER socket. Make sure the power source is on.
4 Push in the POWER button.
5 Look at the lights on the front panel.
• The POWER light blinks while your P-660RU-Tx v2 starts up
and stays on once it is ready.
• The DSL light is on when the P-660RU-Tx v2 has a DSL
connection.
• The USB light turns on if the USB port is properly connected,
and blinks when there is traffic.
