Fig.2 ENGINE GROUP
1
1580-12111
CYLINDER
1
2
1580-12150
STUD
2
3
3310-12281
BOLT
4
4
00260-30525
SCREW
2
5
00260-30550
SCREW
2
6
1400-13121
GASKET
1
7
1420-13130
GASKET
1
8
1580-13140
GASKET
1
9
1400-13150
GASKET
1
10
1580-13160
INSULATOR
1
11
1400-21100
CRANKCASE COMP
1
12
1400-21140
GASKET
1
13
06030-06202
BEARING
2
14
1520-21220
SEAL
1
15
1400-21220
SEAL
1
16
04065-03515
RING
4
17
01252-30530
BOLT
1
18
2155-21311
GUARD
1
19
00263-90514
SCREW
2
20
3360-41110
PISTON
1
21
3360-41211
RING
2
22
3360-41310
PIN
1
23
3350-41320
RING
2
24
1400-41410
BEARING
1
25
2670-41510
WASHER
2
26
1400-42002
CRANKSHAFT COMP
1
27
1300-42410
SHIM
0~1
28
1400-43230
NUT
2
29
1000-43240
KEY
1
30
1075-51113
SHOE
2
31
1075-51220
SPRING
1
32
1200-51211
SCREW
2
33
1200-51230
WASHER
2
34
1200-51240
WASHER
2
35
2073-71110
ROTOR
1
36
2155-71200
COIL ASSY
1
37
2155-71220
• CORD,high
1
38
2616-71320
• CAP
1
39
5500-72130
GROMMET
1
40
1100-72120
GROMMET
1
41
1900-72111
CAP
1
42
1900-72120
SPRING
1
43
00263-90520
SCREW
2
44
1400-15111
MUFFLER
1
45
00263-90512
SCREW
1
46
1140-51230
WASHER
1
47
1580-15230
NUT
1
48
1400-15410
COVER,muffler
1
49
00263-90512
SCREW
3
50
1400-31113
COVER
1
51
3310-12281
BOLT
4
52
1100-72120
GROMMET
1
53
1462-32111
COVER
1
54
00263-90512
SCREW
2
55
1600-86130
CLAMP
1
56
3540-93110
STAND
1
57
3310-31720
BOLT
2
58
2155-71240
CORD
1
59
2116-71250
CORD,earth
1
60
1216-73110
SPARKPLUG
1
RCJ-6Y
61
1487-75000
STARTER ASSY
1
62
1487-75100
• RECOIL ASSY
1
63
1180-75221
• • SPRING
1
64
1487-75120
• • REEL
1
65
1487-75140
• • DOG
1
66
1861-75150
• • WASHER
1
67
1483-75270
• • SCREW
1
68
1487-75160
• • RETAINER
1
69
1487-75170
• • WASHER
1
70
1400-75160
• • ROPE
1
71
1400-75170
• • KNOB
1
72
1487-75211
• PULLEY ASSY
1
73
00263-90520
SCREW
1
74
1584-81000
CARBURETOR ASSY
1
75
1650-81122
• CAP
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
76
1580-81480
• DIAPHRAGM ASSY
1
77
1101-81950
• PACKING
1
78
1420-81150
• VALVE
1
79
1335-81070
• RECEIVE
1
80
1038-81001-29
• SCREW
1
81
1650-81260
• SPRING
1
82
1420-81271
• SCREW
1
83
1420-81370
• SPRING
1
84
1420-81490
• COVER
1
85
1420-81420
• HOLDER
1
86
1420-81410
• JET
1
87
1420-81730
• PACKING
1
88
1420-81720
• PUMP
1
89
1101-81190
• CLIP
1
90
1580-81180
• NEEDLE
1
91
1335-81060
• SPRING
1
92
00260-10310
• SCREW
4
93
1422-81800
• COVER ASSY
1
94
1141-81120
• CAP
1
95
1130-81170
• VALVE
1
96
00260-10308
• SCREW
4
97
1420-81510
• LEVER
1
98
1420-81520
• SPRING
1
99
00260-00408
• SCREW
1
100
1420-81530
• COLLAR
1
101
00260-00306
• SCREW
1
102
1100-81461
• PIN
1
103
1100-81440
• VALVE
2
104
1420-81430
• SPRING
1
105
1420-81450
• LEVER
1
106
1420-81620
• PLATE
1
107
1580-82000
CLEANER ASSY
1
108
1400-82112
• BODY
1
109
1400-82120
• COVER
1
110
1418-82130
• ELEMENT
1
111
1400-82140
• SCREEN
1
112
1580-82150
• PLATE
1
113
1580-82160
• SCREW
1
114
1133-82060
LABEL
1
115
00260-30422
SCREW
2
116
2175-84000
LEVER ASSY
1
117
1638-84110
GRIP-R
1
118
1638-84120
GRIP-L
1
119
1638-84130
• LEVER
1
120
1638-84140
• LEVER
1
121
1638-84150
• LOCK
1
122
1638-84160
• BAND
1
123
2175-84300
• CABLE COMP
1
124
1638-84170
• SPRING
1
125
1638-84180
• SPRING
1
126
00263-60620
• SCREW
1
127
1638-84190
• NUT
1
128
00260-60535
• SCREW
1
129
1638-84210
• NUT
1
130
1638-84220
• SCREW
1
131
1439-85000
TANK ASSY
1
132
2116-85201
• CAP ASSY
1
133
2116-85300
• • VALVE COMP
1
134
1600-85322
• • • PACKING
1
135
3317-57242
• • STOPPER
1
136
1435-85401
• FITER ASSY
1
137
1421-85400
• PUMP COMP
1
138
1260-85460
• CLIP
1
139
1063-86130
CLIP
1
140
1420-86180
PIPE
1
141
1400-86214
SUPPORT
1
142
00263-90520
SCREW
2
143
1400-86250
COLLAR
2
144
1460-85250
SCREW
2
145
1400-86260
COLLAR
2
146
1400-86271
CUSHION
2
147
1400-86280
WASHER
2
148
1580-86290
PLATE
1
149
1660-31121
LABEL
1
150
1580-75412
LABEL
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
BC530WE
